A grid-based level editor for Unity, built with UI Toolkit. It lets you author, manage and preview tile-and-block levels stored as ScriptableObjects — directly in the editor and at runtime.

The tool is split into two editor windows and a runtime generator:

• Block Library — define reusable block types (id, icon, prefab, footprint).
• Level Editor — paint levels on a grid using drag-and-drop, with selection, rotation, copy/paste and undo/redo.
• Runtime Generator — spawns the authored level in the scene with staggered DOTween animations and optional auto-switching between levels.

Levels and blocks are plain ScriptableObjects under Assets/Resources/StaticData, so they are versionable and load through the standard static-data pipeline.

• Dedicated window (Tools → Grid Level Editor → Block Window).
• Create, rename and delete block types; assign id, icon and prefab.
• Define multi-cell footprints (rectangle, L, T, cross, …) on a paint grid.
• Search and sort by id, prefab or icon name.

• Visual grid editor (Tools → Grid Level Editor → Level Window).
• Create, rename, resize and delete levels.
• Drag blocks from the palette onto the grid; multi-cell objects render as a single merged plate that follows their exact footprint.
• Range selection, rotation, copy/paste and a per-level undo/redo history.
• Context menu (right click) for block selection, rotation, copy/paste and clearing.
• Built-in log panel and a controls overlay.

• Spawns floor tiles and blocks from the authored level data through injected factories.
• Staggered show/hide animations via DOTween.
• One block per object is spawned at the object's geometric center.
• Optional auto-switching to the next level on a configurable interval.

Undo/redo is window-local and scoped to the current level: the history resets when you switch levels and when the window is closed.

1. Open the project in Unity 2023.2 or newer.
2. Open Tools → Grid Level Editor → Block Window and create a few blocks (id + icon required; prefab optional).
3. Open Tools → Grid Level Editor → Level Window, create a level, then drag blocks onto the grid.
4. Enter Play mode to see the level spawned by the runtime generator.

Data locations:

• Levels — Assets/Resources/StaticData/LevelsData
• Blocks & library — Assets/Resources/StaticData/BlocksData

The grid is stored as a flat, row-major LevelCell[] (Unity cannot serialize 2D arrays) and addressed through Index(x, y). Multi-cell blocks share a positive InstanceId; standalone cells use 0.

• Unity 2023.2
• UI Toolkit (editor UI)
• Zenject (dependency injection)
• DOTween (runtime animation)
• Odin Inspector (serialization in SaveLoadService)
